CyberPower Systems
CyberPower Systems PFC Sinewave 1600VA Tower UPS with LCD
CyberPower Systems PFC Sinewave 1600VA Tower UPS with LCD
Couldn't load pickup availability
Product Description
Ideal for protecting: Computers and peripherals, Business Telephony, Network Devices, POS Equipment
CyberPower Systems PFC Sinewave 1600VA Tower UPS with LCD designed for home, office and back office applications, the PFC Sinewave Series adopts line-interactive topology with Automatic Voltage Regulation (AVR) function to offer stabilised Pure Sine Wave output. The products are compatible with equipment requiring active PFC power supply. Other features include RJ45 port to provide data line protection as well as supply 1Gbps speed to transmit data, tiltable colour LCD panel to display key information at a glance and power management software to achieve real-time monitoring and configuration.
The included PowerPanel Personal Edition management software showcases the feature rich abilities such as input/output power voltage readings, self-diagnostics, and approximate battery backup time. With the Energy Saving Technology, PFC Sinewave UPS Series can help save energy cost and contribute to environmental protection.
| Technology: | PFC Sinewave (Line-Interactive) |
| Rating: | 1600VA |
| Voltage: | 230Vac |
| Configuration: | Tower |
Technical Specifications
Output
| Capacity (VA) | 1600 |
| Capacity (Watts) | 1000 |
| On Battery Waveform | Pure Sinewave |
| On Battery Voltage (Vac) | 230 +/- 5% (Under a test load of <60%. When the load >60%, the output voltage range may >5%) |
| On Battery Frequency (Hz) | 50/60 +/- 1% |
| Outlet Type |
(6) x AU |
| Outlet(s) - Battery & Surge Protected |
6 |
| USB Charging Port(s) |
USB-A x 1 USB-C x 1 |
| USB Charging Total Output (Watts) |
30 |
| Typical Transfer Time (ms) |
8 |
Input
| Nominal Input Voltage (Vac) | 220, 230, 240 |
| Input Voltage Range (Vac) | 169 - 271 |
| Input Frequency (Hz) | 50/60 +/- 3 |
| Input Frequency Detection | Auto Sensing |
| Rated Input Current (A) | 10 |
| Input Connector Type | IEC C14 |
| Detachable Power Cord Plug Type | AU x 6 |
Batteries & Runtime
| Runtime at Half Load (min) | 9.7 |
| Runtime at Full Load (min) | 2.6 |
| Typical Recharge Time (Hours) | 8 |
| Battery Type | Sealed Lead-Acid |
| User Replaceable | Yes |
| Replacement Battery Pack | RBP0142 |
| RBP Quantity (pcs) | 1 |
Physical
| Height | 28.15 cm |
| Width | 10.0 cm |
| Depth | 35.41 cm |
| Weight | 11 kg |
| Colour | Black |
