CyberPower Systems
CyberPower Systems Online High Density 6000VA Tower/Rack Mount UPS
CyberPower Systems Online High Density 6000VA Tower/Rack Mount UPS
Couldn't load pickup availability
Product Description
Ideal for protecting: Computers and peripherals, Network Devices, Servers, Switches, Workstations, Data Centres, Industrial Equipment
CyberPower Systems Online High Density 6000VA Tower/Rack Mount UPS OL6KERTHD guarantees power backup protection for IT equipment, servers, workstations, NAS/Storage devices, telecom devices, networking devices, security/emergency systems and surveillance systems. The UPS adopts double conversion topology to provide high quality power output in a compact design. This generator compatible UPS features hot-swappable battery packs for maintenance without power interruption and comes with additional ECO Mode to conserve power and save on energy costs.
The UPS can employ Extended Battery Modules (EBM) to prolong runtimes and adopts patent Battery Management Technology to balance battery string voltage for optimal battery lifespan. This model also features tiltable colour LCD panel that allows users to monitor key power and battery information at a glance. The PowerPanel Power Management Software allows user to perform real-time monitoring and remote management of the UPS.
| Technology: | Online (High Density) Series |
| Rating: | 6000w / 6000VA |
| Voltage: | 240Vac |
| Configuration: | Towr or Rack Mountable |
Technical Specifications
Output
| Capacity (VA) | 6000 |
| Capacity (Watts) | 6000 |
| On Battery Waveform | Pure Sinewave |
| On Battery Voltage (Vac) | 200 +/- 2%, 208 +/- 2%, 220 +/- 2%, 230 +/- 2%, 240 +/- 2% |
| On Battery Frequency (Hz) | 50/60 +/- 0.5% |
| Outlet Type |
(2) x IEC C19 (4) x IEC C13 (1) x Hardwire Terminal Block |
| Typical Transfer Time (ms) |
0 |
Input
| Nominal Input Voltage (Vac) | 200 - 240 |
| Input Voltage Range (Vac) | 180 - 280 |
| Input Frequency (Hz) | 50/60 +/- 10 |
| Input Frequency Detection | Auto Sensing |
| Rated Input Current (A) | 32 |
| Input Connector Type | Hardwire Terminal Block |
Batteries & Runtime
| Runtime at Half Load (min) | 4.9 |
| Runtime at Full Load (min) | 1.4 |
| Typical Recharge Time (Hours) | 4 |
| Battery Type | Sealed Lead-Acid |
| Battery Quantity | 1 |
| User Replaceable | Yes |
| Hot-Swappable | Yes |
| Replacement Battery Pack | RBP0144 |
Physical
| Height | 8.65 cm |
| Width | 43.3 cm |
| Depth | 72 cm |
| Rack Height | 2U |
| Weight | 42 kg |
| Colour | Black |
